DJI AS1 Speaker

In the Box

• Speaker × 1
• Spare Adapter Bracket × 1
• Hex Key × 1

Overview

Delivering greater reach and increased volume, the DJI AS1 Speaker delivers up to 114 decibels at 1 meter, with a broadcast range extending up to 300 meters.[1] It supports recorded messages, media imports, and text-to-speech conversion.[2] The speaker also features real-time broadcasting with echo suppression[3]. It can function independently or be paired with a spotlight, providing versatility for a wide range of operational scenarios.

Highlights

• Achieves a maximum volume of 114 decibels at 1 meter
• Broadcast range reaches up to 300 meters

Tips

1. Secure the installation by tightening the screws using the provided hex key. For ongoing use, remember to re-tighten the screws after installation.
2. When pairing the speaker with a spotlight, detach the speaker adapter bracket.
3. Once installation is complete, power on the speaker and calibrate the aircraft compass as per the app’s instructions. If prompted, update the firmware to the latest version.
4. Refrain from using the speaker near people or in urban areas with noise-sensitive buildings to prevent accidents or injuries due to high volume.
5. Avoid playing single-frequency sounds to prevent causing permanent damage to the speaker.

Specifications

• Weight: 92.5 g (including bracket), approx. 90 g (excluding bracket)
• Dimensions:
  • 73 × 70 × 52 mm (L × W × H, including bracket)
  • 73 × 70 × 47 mm (L × W × H, excluding bracket)
• Max Power: 15 W
• Max Volume: 114 dB at 1 meter
• Effective Broadcast Range: 300 meters
• Broadcast Modes: Real-time broadcasting (supports echo suppression), recorded broadcasting, media import (supports simultaneous transmission and playback), text-to-speech [2]
• Operating Temperature: -4° to 122° F (-20° to 50° C)
• Mounting Method: Quick-release hand-tightened screws

Compatibility

• DJI Matrice 4 Series aircraft
